The advantages of low noise and no exhaust emission have also been recognized by many users.\
Configure:
Mode |
CPD20 |
CPD25 |
CPD30 |
CPD35 |
Power |
Storage Battery |
Loading Capacity |
2000 |
2500 |
3000 |
3500 |
ELoad Center Distance |
500 |
Operator Type |
Sit Down |
Overall |
Fork L1 |
3380 |
3380 |
3630 |
3630 |
No Fork L2 |
2310 |
2310 |
2560 |
2560 |
Overall Width B |
1150 |
1150 |
1220 |
1220 |
Total Height |
Door Frame Height H1 |
2000 |
2000 |
2080 |
2080 |
Height Of Retaining Frame H2 |
2145 |
2145 |
2215 |
2215 |
Max. Height During Operation |
3995 |
3995 |
4185 |
4185 |
Distance From Seat Surface To Top Shield |
1020 |
1020 |
1060 |
1060 |
Wheelbase L4 |
1515 |
1515 |
1680 |
1680 |
Front Suspension Distance Y |
483 |
483 |
490 |
490 |
Rear Distance L5 |
400 |
400 |
425 |
425 |
Front Wheel Tread R |
970 |
970 |
1000 |
1000 |
Rear Wheel Tread P |
950 |
950 |
980 |
980 |
Min. Height Off The Ground F |
135 |
135 |
145 |
145 |
Max. Lifting Height H |
3000 |
Free Lifting Height H4 |
170 |
170 |
160 |
160 |
Fork Adjustable Range S |
1024/200 |
1024/200 |
1060/250 |
1060/250 |
Min. Outside Turning Radius WA |
2050 |
2050 |
2200 |
2200 |
Minimum Right Channel Width |
3760 |
3760 |
4100 |
4100 |
Door Frame Dip Angle(Font/Rear) a/β |
6°/12° |
6°/12° |
6°/12° |
6°/12° |
Max. Lifting Speed With Empty Load |
400 |
380 |
450 |
425 |
Max. Lifting Speed With Full Load |
300 |
280 |
280 |
260 |
Max.Driving Speed With Empty Load |
15 |
15 |
14 |
14 |
Max. Driving Speed With Full Load |
14 |
14 |
12.5 |
12.5 |
Max.Gradient With Full Load |
≤15 |
Net Weight |
4050 |
4200 |
4950 |
5600 |
Wheel Number X=Driving Wheel(Front/Rear) |
2x/2 |
Tyre Type(Front/Rear) |
Solid Tyre |
Front Tyre |
7.00-12 |
7.00-12 |
28×9-15 |
28×9-15 |
Rear Tyre |
18×7-8 |
18×7-8 |
18×7-8 |
18×7-8 |
Brake |
Hydraulic Pedal |
Parking Brake |
Machinery-Manual Type |
Storage Battery Voltage/Capacity |
48/500 |
48/500 |
80/500 |
80/500 |
Drive Motor Power |
DC11 |
DC11 |
DC16.6 |
DC16.6 |
Pump Motor Power |
Features:
The door frame adopts thickened steel, high strength and not easy to deform, stable lifting and dropping, low noise.
- Thickened Multilayer Plate Chain
Strong pull, easy lifting, thickening prevent safety accidents.
Safe and durable, heavy load bearing, the width can be adjusted freely according to the size of cargo.
- LED High Quality Light Group
LED high - quality lamp group saves power, brightness and long service life.
The humanized design, the configuration seat belt, the driving is more comfortable, not easy to fatigue, greatly enhances the work efficiency.
- Full Hydraulic Steering System
More smooth steering, fast positioning, ensuring driver safety.
Press this button for an emergency stop to immediately cut off all power supply and ensure safety.
- Wear Resistant Solid Tires
Solid and thick rubber ring is adopted before and after, which greatly increases the climbing ability of forklift to adapt to different road surface.
- New Wide Field Door Frame
Less visual dead Angle, high strength load, not easy to deformation, and with load cargo drop buffer function.
Humanized design of steering wheel can improve driving comfort and correct operation can reduce abnormal wear of steering parts and tires.
- Large Capacity Combination Battery
Sustainable use of more than 6 hours, so that better operators to improve work efficiency.
