Features:
Capable of AC 44kW and DC 50kW fast charging simultaneously
- Complying with European and Japanese standard
- 50 to 500V wide output voltage range, suitable to various vehicles
Tested by authorities, CE certified
High DC charging fficiency, designed to deliver full output power continuously
- Supporting OCPP, enable itelligent monitoring with back office system and mobile app
- Supporting remote maintenance and online upgrade
- Multi-language itelligent touch screen HMI, independent operating interfaces for AC and DC
- Supporting various payment methods, including credit card quick pass
Modular design, easy to scale and maintain
- Multiple protections, including auto power off, overcharge protection and failure isolation, etc.
- Efficient heat dissipation, resistant to water and dust, stable operation in harsh environments such as high and low temperature, rainy and snowy conditions, etc.
Technical Data:
Model |
ZEVQC-44-50-U3M |
Input |
AC power connection |
3P + N + E |
Input voltage range (V) |
AC 400±10% (50 Hz) |
Max. rated input current (A) |
150 |
Max. rated input power (kVA) |
100 |
Power factor (full load) |
>0.99 |
Output |
|
AC output |
Combo Typ 2 |
2 CHAdeMO |
Max. output power (kW) |
44 |
50 |
50 |
Output voltage range (V) |
AC400± 10% |
DC200-500 |
DC50-500 |
Max. output current (A) |
3x63 |
125 |
125 |
Efficiency (%) |
99 |
95 |
95 |
Connector/plug Type |
IEC/EN62196 Mode 3,Typ 2 |
Combo Typ 2 |
CHAdeMO/JEVS G105 |
General |
RFID-System |
Visa/Master, Mifare |
Networking |
Ethernet (standard), 3G/4G (optional) |
Platform communication protocol |
OCPP 2.0 |
User interface |
Glare-free 7-inch touch screen, displaying the charging process |
Metering |
MID (Measuring Instruments Directive) 2004/22/EG |
Protection level |
IP54 |
Noise (dBA) |
s65 |
Cable length (m) |
5 |
Dimensions: WxDxH (mm) |
750x700x1900 |
Environmental |
Installation |
Indoor or outdoor |
Operating temperature (°C) |
-30 to 55 |
Storage temperature (°C) |
-40 to 70 |
Conformity and safety |
CE |
