Features:
- High adaptability, suitable for all kinds of EVs
- High-speed CAN communication bus for real-time detection and monitoring of power modules
- Adopting advanced 6th generation DSP control, higher system reliability, online upgrade enabled
- Online self-diagnosis, convenient system maintenance
- Safe and reliable, with multiple protections: automatic power-off for abnormal charging, overcharge protection and failure isolation, etc.
- Optional installation methods, can be placed anywhere or mounted on a wall
- Simple operation interface, one-button switch on/of
Key Benefits:
1.Charging anywhere with a 32A/16A 220V AC power supply (for 6.6kW charger)
2.One-button power on/off, one-button display contro
1.Rated efficiency of up to 95.5%
2.Power factor ≥ 0.99, standby power draw < 12W
1.6.6kW charger dimension of only 433×158×240mm
2.Modular design, easy to integrate and maintain
Small and light, handle or wheel design, easy to carry and transport
Technical Data:
Model
|
ZEVQC-7/750-P1
|
ZEVQC-15/750-P1
|
ZEVQC-45/750-P1
|
Input voltage (V)
|
220+PE
|
380 / three-phase five-wire
|
Input frequency (Hz)
|
45 - 65
|
Power factor
|
≥0.99
|
Max. input current (A)
|
32 (220V AC input)
|
30 (380V AC input)
|
90 (380V AC input)
|
Output power (kW)
|
6.6
|
15
|
45
|
Output current (A)
|
13.2
|
25
|
75
|
Output voltage (V)
|
DC200-750
|
Charging interfaces
|
CCS2, GB/T
|
Stabilized voltage precision (%)
|
≤±0.5
|
Stabilized current precision (%)
|
≤±1
|
Ripple factor (%)
|
≤1
|
Efficiency (%)
|
≥94
|
≥95.5
|
Noise (dB)
|
≤65
|
Auxiliary power supply
|
12V/5A
|
12V/10A
|
Storage temperature (℃)
|
-40 to 70
|
Operating temperature (℃)
|
-20 to 40 (derating output from 40℃ to 65℃)
|
-20 to 60 (derating output from 60℃ to 75℃)
|
Humidity (%)
|
5-95 ( non-condensing)
|
Altitude (m)
|
≤2000
|
Protection level
|
IP21
|
Dimensions (W×D×H,mm)
|
433×158×240
|
510×200×267
|
550×320×560
|
Body material
|
Metal
|
Input cable length (m)
|
5
|
4
|
3
|
Output cable length (m)
|
2.5
|
4
|
2
|
Protections
|
Over-voltage, under-voltage, over-current, short circuit, over-temperature, battery reversal, communication failure
|
LED
|
√
|
Online upgrade
|
√
|
