Shipping :
Support Sea FreifgtCustomization :
Customized Logo, Customized PackagingDelivery Time :
By ProductWarranty :
By ProductSpeific Information:
| Transport type | Heavy haul transportation | ||||
| Logistics type | Concrete | Bulk cement | |||
| Distance(km) | ≤50 | ≤300 | |||
| Road type | Paved roads | Paved rood | |||
| Drive | 6x4 | 6x4 | 8x4 | 8x4 | |
| Max weight(t) | ≤40 | ≤40 | ≤50 | ≤50 | |
| Max speed(knVh) | 85 | 70 | 85 | 85 | |
| Road type | Paved roads | Paved roads | Paved roads | Paved roads | |
| Loaded speed(kmZh) | 40 〜60 | 40 〜60 | 40 〜60 | 40 〜60 | |
| Vehicle model | SX5255GJBDR384 | SX5255GJBDR384C | SX5315GJBJT306 | SX5315GSNDU456 | |
| Engine(km/h) | WP10.340E22+PTO | 1SME345 30+PTO | WP10.380E22+PTO | WP12.400E201 | |
| Emission standard | Euro II | EuroIII | Euro II | Euro II | |
| Displacement | 9.726L | 10.8L | 9.726L | 11.596L | |
| Rated Output | 250kW | 254kW | 280kW | 294kW | |
| Max. torque | 1350Nm | 1710Nm | 1600Nm | 1800Nm | |
| Transmission | 10JSD180 | 10JSD180 | 10JSD180 | 12JSD200T-B with QH70 | |
| Clutch | 430 | 430 | 430 | 430 | |
| Frame | 850x300(8+7) | 850x300(8+7) | 850x300(8+7) | 850x300(8+7) | |
| Front axle | MAN 9.5T | MAN 9.5T | MAN 9.5T | MAN 9.5T | |
| Rear axle | 16TMAN 5.92 | 16TMAN 5.262 | 16TMAN 5.262 | 16TMAN 5.262 | |
| Tire | 12.00R20 | 12.00R20 | 12.00R20 | 12.00R20 | |
| Front Suspension | Multi leaf springs | Multi leaf springs | Multi leaf springs | Multi leaf springs | |
| Rear Suspension | Multi leaf springs | Multi leaf springs | Multi leaf springs | Multi leaf springs | |
| Fuel | Diesel | Diesel | Diesel | Diesel | |
| Capacity of the fuel tank | 400L | 400L | 400L | 400L | |
| Battery | 165 Ah | 180Ah | 165 Ah | 165 Ah | |
| Dimensions(LxWxH) | 8475x2495x3774 | 8475x2495x3774 | 10725x2495x3774 | 11725x2495x3774 | |
| Vblume(m,) | 10 | 10 | 12 | 40 | |
| Wheelbase | 3775+1400 | 3775+1400 | 1800+2975+1400 | 1800+4575+1400 | |
| Max .gradeabi 1 ity(%) | 34 | 34 | 34 | 27 | |
| Cab | Type | F3000, lengthened flat roof | |||
| Equipments | ♦ Hydraulic main seat ♦ Four point hydraulic suspension cab ♦ Automatic air conditioning ♦ Electric window lifter ♦ Manual flip | ||||
| Optional | ♦ Airbag main seat • Central locking | ||||
Details:
1,American VISTEON technology interior adopts 100% natural negative ion fiber fabric: new material sleeper berth can promote rest quality, Timed air conditioning external eyele and activated carbon air filter can inerease cab air quality.
2,Sedan dashboard with new multi-functional VDO instruments includes controls AC, MP3 and radio.
3,Driver and passenger side are both equipped with easy-operating and adjustable sunshades.
4,Integrated structure floor mat is equipped with proteetive strips, great insulation and sealing, easy to clean and with good noise reduction properties.
5, Telescopic shaft shift system is fixed shift lever base for increasing cab sealing properties and engine noise reduction.
6, Four point air suspended auto adjusting seat design according to man-machine curve, providing its occupants with superior quality and comfort , The seat is effective in reducing driver fatigue which ensures the driver have a safe and comfortable journey.
7, Advanced SIS suspension system is light weight maintenance free and with good load balance . New type steel plate spring suspension is equipped with high quality shock absorber and front &rear axle stabilizer bar, The new type of balanced suspension allows better load capacity and durability.
Full drive tractor，Bulk cement ，Bulk tank transport
A dump truck, known also as a dumping truck, dump trailer, dumper trailer, dump lorry or dumper lorry or a dumper for short, is used for transporting materials for construction as well as coal.
All-new body design, advanced sound insulation technology and reinforced cab body structure, four-point air suspension system, double-layer sealed cab door and electronically controlled automatic climate control increase driving comfort.
All-new body design, advanced sound insulation technology and reinforced cab body structure, four-point air suspension system, double-layer sealed cab door and electronically controlled automatic climate control increase driving comfort.
A crane truck is a crane/telescopic crane on the chassis of a truck. Through a telescopic boom, the crane extends to 8 times its original length.
A truck or lorry is a motor vehicle designed to transport cargo, carry specialized payloads, or perform other utilitarian work. Trucks vary greatly in size, power, and configuration, but the vast majority feature body-on-frame construction, with a cabin that is independent of the payload portion of the vehicle.
A tank truck, gas truck, fuel truck, or tanker truck or tanker is a motor vehicle designed to carry liquids or gases on roads. The largest such vehicles are similar to railroad tank cars, which are also designed to carry liquid loads.
Browse a large selection of all mixer trucks from top manufacturers Popular models include MAN 9.5T, WP10.340E22+PTO, SX5255GJBDR384. Additional services available including financing, insurance and warranties on select mixer trucks.
