Feature:
1.High-power permanent magnet synchronous drive motor with a max power of 150kw and top torque up to 1000N.M.
2. The use of integrated high-voltagecontroller, by optimizing the electronic control system, the rated power of electric motor is increased by 4%, which improves the high-speed power performance of InTour. At the same time, the energy consumption of the motor will be reduced by 8%, which can effectively extend the drivng range.
3.Using lightweight body technology and three-dimensional vehicle design to reduce the weight of the vehicle and increase the pure electric driving range of the vehicle.
4.The front and rear disc brakes greatly shorten the braking distance and make driving safer.
5.The front and rear exterior can be opened as a whole to ensure the convenience of maintenance.
6.InTour is equipped with an integrated electrical box for intergrating bus module, ABS/ECU.
7.The high-voltage wiring harness is fixed by a bridge frame, which is convenient for maintenance and separates high and low voltage, which effectively avoids interference.
Technical Specification:
Dimension(mm) |
6540/2100/3000 |
Wheelbase (mm) |
3320 |
Curb Weight(kg) |
5500 |
Max.Passenger Capacity |
35 |
Max Gradability (%) |
≥15 |
Brake System |
Double-circuit air brake,front/rear disk type |
Door Arrangement |
Middle door |
Gross Weight (KG) |
9500 |
Max Power Output (KW) |
60/150 |
Max Torque(N·M) |
340/1000Battery Type |
Battery Type |
LFP |
Battery Capacity |
128kwh |
Tire |
MICHELIN 215/75R17.5 |
ABS |
Equipped |
ASR |
Equipped |
EBS |
Equipped |
